PURE
At just 5 cm thick, seamless and defined by rounded corners, PURE integrates elegantly into any architectural setting, offering a natural balance between form and function. Available in multiple formats – including an Acoustic version – it stands out for its lighting versatility: it can be fitted with a PG diffuser for soft, uniform emission, or with a microprismatic (MP) diffuser for optimal visual comfort in workspaces, combined with Fly Eyes modules for technical, precise, and controlled illumination.
Thanks to a dedicated accessory bracket, PURE can also be configured in modular compositions with customized geometries, adapting flexibly to the most complex design requirements.
Thanks to a dedicated accessory bracket, PURE can also be configured in modular compositions with customized geometries, adapting flexibly to the most complex design requirements.
Technical features
Optics
Body
Legal references
Certifications
On request
Colors
- Integrated driver
- PG diffuser in impact-resistant satin acrylic with UGR<22
- MP technology for controlled glare with UGR<19
- Shade UGR<16
- 3000K / 4000K
- CRI >90
- Eye safety: RG0 / RG1
- MacAdam 3
- L80/B20 >80,000h
- IP40
- Direct emission
- Direct/indirect emission
- UGR <16; <19; <22
Epoxy powder-coated aluminium.
The fixtures comply with safety standards EN 60598-1 and UNI EN 12464-1 (lighting of work environments). The DALI product complies with CAM Edilizia DM 23 June 2022 No. 256, lighting sector.
- CE compliance
- Energy class C
- 5-year warranty
- DALI – code D
- Bluetooth – code BT
- Emergency 1 h – code EM
- Emergency 3 h – code EM3H*
- 2700K – code K27*
Check availability
-
White RAL 9003 wrinkled – code W
-
Black RAL 9005 wrinkled – code BK
-
Other colours – on request
Technical features
- Integrated driver
- PG diffuser in impact-resistant satin acrylic with UGR<22
- MP technology for controlled glare with UGR<19
- Shade UGR<16
- 3000K / 4000K
- CRI >90
- Eye safety: RG0 / RG1
- MacAdam 3
- L80/B20 >80,000h
- IP40
Optics
- Direct emission
- Direct/indirect emission
- UGR <16; <19; <22
Body
Epoxy powder-coated aluminium.
Legal references
The fixtures comply with safety standards EN 60598-1 and UNI EN 12464-1 (lighting of work environments). The DALI product complies with CAM Edilizia DM 23 June 2022 No. 256, lighting sector.
Certifications
- CE compliance
- Energy class C
- 5-year warranty
On request
- DALI – code D
- Bluetooth – code BT
- Emergency 1 h – code EM
- Emergency 3 h – code EM3H*
- 2700K – code K27*
Check availability

PURE
versions
MP COMBO
ACOUSTIC
PURE PG DOUBLE EMISSION
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77DI62PGK4
50W+12W 4000K
10540lm
595x595mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77DI62PGK3
50W+12W 3000K
9796lm
595x595mm
Standard
Dimmable
Emergency
PURE PG COMBO
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77PG55K4WQ
32W+23W 4000K
10030lm
595x595mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77PG55K3WQ
32W+23W 3000K
9322lm
595x595mm
Standard
Dimmable
Emergency
PURE PG
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77PG50K4
50W 4000K
8500lm
595x595mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77PG50K3
50W 3000K
7900lm
595x595mm
Standard
Dimmable
Emergency
PURE PG Long
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77PG24K4M
24W 4000K
4080lm
295x595mm
Standard
Dimmable
Emergency
77PG50K4L
50W 4000K
8500lm
295x1195mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77PG24K3M
24W 3000K
3792lm
295x595mm
Standard
Dimmable
Emergency
77PG50K3L
50W 3000K
7900lm
295x1195mm
Standard
Dimmable
Emergency
PURE PG DOUBLE EMISSION Long
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77DI36PGK4M
24W+12W 4000K
6120lm
295x595mm
Standard
Dimmable
Emergency
77DI62PGK4L
50W+12W 4000K
10540lm
295x1195mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77DI36PGK3M
24W+12W 3000K
5688lm
295x595mm
Standard
Dimmable
Emergency
77DI62PGK3L
50W+12W 3000K
9796lm
295x1195mm
Standard
Dimmable
Emergency
PURE PG COMBO Long
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77PG34K4WQL
17W+17W 4000K
6460lm
295x1195mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77PG34K3WQL
17W+17W 3000K
6004lm
295x1195mm
Standard
Dimmable
Emergency
PURE MP
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77MP50K4
50W 4000K
7500lm
595x595mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77MP50K3
50W 3000K
6900lm
595x595mm
Standard
Dimmable
Emergency
PURE MP DOUBLE EMISSION
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77DI62MPK4
50W+12W 4000K
9300lm
595x595mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77DI62MPK3
50W+12W 3000K
8556lm
595x595mm
Standard
Dimmable
Emergency
PURE MP COMBO
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77MP55K4WQ
32W+23W 4000K
8850lm
595x595mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77MP55K3WQ
32W+23W 3000K
8142lm
595x595mm
Standard
Dimmable
Emergency
PURE MP Long
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77MP24K4M
24W 4000K
3600lm
295x595mm
Standard
Dimmable
Emergency
77MP50K4L
50W 4000K
7500lm
295x1195mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77MP24K3M
24W 3000K
3312lm
295x595mm
Standard
Dimmable
Emergency
77MP50K3L
50W 3000K
6900lm
295x1195mm
Standard
Dimmable
Emergency
PURE MP DOUBLE EMISSION Long
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77DI36MPK4M
24W+12W 4000K
5400lm
295x595mm
Standard
Dimmable
Emergency
77DI62MPK4L
50W+12W 4000K
9300lm
295x1195mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77DI36MPK3M
24W+12W 3000K
4968lm
295x595mm
Standard
Dimmable
Emergency
77DI62MPK3L
50W+12W 3000K
8556lm
295x1195mm
Standard
Dimmable
Emergency
PURE MP COMBO Long
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77MP34K4WQL
17W+17W 4000K
5700lm
295x1195mm
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77MP34K3WQL
17W+17W 3000K
5244lm
295x1195mm
Standard
Dimmable
Emergency
PURE ACOUSTIC DOUBLE EMISSION
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77AC23K4WQ
23W 4000K
2349
595x595
Standard
Dimmable
Emergency
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77AC23K3WQ
23W 3000K
2268
595x595
Standard
Dimmable
Emergency
PURE PG Mini
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77PG13K4
13W 4000K
2210
295x295
Standard
Dimmable
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77PG13K3
13W 3000K
2054
295x295
Standard
Dimmable
PURE PG COMBO Mini
PURE

Datasheets
4000K
code

flux
size
wiring
datasheet
specification items
77PG25K4WQ
15W+10W 4000K
4590
295x295
Standard
Dimmable
Datasheets
3000K
code

flux
size
wiring
datasheet
specification items
77PG25K3WQ
15W+10W 3000K
4266
295x295
Standard
Dimmable
